General
Cable Categories | Indoor |
Cable Type | Loose Tube, Non-armored |
Fiber Type | Bend Insensetivie MultiMode, 50/250um, OM3 |
Fiber Count | 12 |
Flame Rating | Riser (OFNR) |
Application | Distribution |
Environmental Specifications
Operating Temperature | -20°C ~ 70°C |
Installation Temperature | -10°C ~ 60°C |
Storage and Shipping Temperature | -40°C ~ 70°C |
Cable Structure
Cable Type | Loose Tube, Distribution |
Outer Diameter, Jacket | 4.1 mm |
Color, Outer Jacket | Aqua |
Number of Subunit | 1 |
Outer Diameter, Subunit | 2.0 mm |
Fibers per Subunit | 12 |
Color, Subunit | Aqua |
Fiber Color | Blue,Orange,Green,Brown,Slate,White,Red,Black,Yellow,Violet,Rose,Aqua |
Tensile Strength Elements | Aramid Yarns |
Mechanical Specifications
Max. Tensile Strength, Short-Term | 440 N |
Max. Tensile Strength, Long-Term | 132 N |
Max. Crush Strength, Short-Term | 100 N/cm |
Min. Bend Radius Installation | 61.5 mm |
Min. Bend Radius Operation | 41 mm |
Optical Specifications, Cabling
Maximum Attenuation | 2.8 dB/km / 1.0 dB/km |
Wavelengths | 850 nm / 1300 nm |
Fiber Compliance | IEC 60793-2-10 |
Minimum Effective Modal Bandwidth (EMB) | 2000 MHz*km @850nm |
Min. Overfilled Launch (OFL) Bandwidth | 1500 MHz*km @850nm |
Max. Macro Loss, 7.5mm Mandrel Radius, 2 Turn | 0.2 dB @850nm (Uncabled) |
Max. Macro Loss, 15mm Mandrel Radius, 2 Turn | 0.1 dB @850nm (Uncabled) |
Standards
Cable Qualification Standards | ANSI/ICEA S-83-596, Telcordia GR-409-CORE, IEC 60794-2-20 |
Flame Rating Standards | UL-1666 |
RoHS | Compliant with 2011/65/EU and (EU) 2015/863 |
Packaging Information
Packaging Quantity | 1 |
Cable Weight | 22 kg/km |
