SN® duplex patch cords are optimized for ultra-high-density fiber optic networks, combining robustness and flexibility while delivering superior optical performance in a variety of deployment environments. Each component uses two fibers encased in a single 2mm circular LSZH jacket, ideal for backbone links, patch panels, cross-connects, and direct device termination.
All components are available in single-mode (OS2) and multimode (OM4, OM5) fiber types, precision terminated with SN® connectors, and factory tested to meet stringent international standards such as GR-326, TIA/EIA, and IEC, providing proven low-loss, high-reliability performance.
Characteristic
- SN connectors enable individualduplex fiber breakout for quad-channel transceivers (QSFP. QSFP -DD. OSFP), delivering higher efficiency, greater reliability, and lower cost compared to MPO connectors
- The duplex design utilizes a unique push-pull boot for easy installation and removal
- SENKO SN VSFF compact connectors enable 4x higher fiber cabling density
- A single QSFP-DD/OSFP transceiver supports four SN patch cables
- 100% factory pre-terminated and tested to guarantee its transmission performance
- Available with multiple flame-retardant jacket ratings: LSZH, OFNR, and OFNP
