MT-FA FAU is a high-precision multi-core optical interconnection component designed for high-speed optical communication, silicon photonics, and co-packaged optics applications. It integrates an MT multi-core connector on one end and a fiber array on the other, enabling low-loss, high-precision coupling between standard MT interfaces and silicon photonic chips, waveguide devices, or optical engines.
Characteristics
- Supports 4/8/12/24-core configurations, ideal for space-constrained optical modules and data centers.
- Typical insertion loss ≤0.35dB, with high return loss (≥60dB for APC polish), ensuring stable high-speed transmission up to 800G/1.6T.
- Core pitch accuracy up to ±0.5µm, enabling reliable coupling with silicon photonic waveguides and optical chips.
- 100% factory-terminated and tested to guarantee consistent performance, eliminating on-site termination errors.
- Meets IEC 61754, Telcordia GR-1435, and domestic industry standards (YD/T 778, GB 2423.17).
